Temperature measurement plays a critical role in monitoring processes across scientific and industrial applications. Therefore, the ability to measure temperatures quickly and accurately is a primary objective for almost every industrial context. A thermocouple probe is one of the modern tools that can achieve this purpose. These temperature sensors hold extreme pressures, high temperatures, and intense vibrations.
This post explains all you need to know about a thermocouple probe and how it works.
Defining Thermocouples
Also known as a thermal or thermal junction, a thermocouple is an electromotive sensor designed to measure temperatures. The device is made up of two dissimilar metals joined together and connected to a thermometer to form a thermocouple junction. The other end is terminated at a cold junction, popularly known as a reference junction.
In most cases, the two thermocouple wires are color coded for ease of identification.
When there is a variance in temperate at the thermocouple junction, a voltage is produced. The voltage is then applied to calculate temperatures.
The popularity of thermocouples is attributed to their versatility, wide range of measurements, durability, interchangeability, and low cost.
What is a Thermocouple Probe?
A thermocouple probe is a thermocouple type where the two dissimilar metals of the temperature sensor are housed in a metallic tube. Typically, the wall of the tube is built with a range of materials with varying performance capacities. For instance, stainless steel thermocouple probes are highly compatible with chemicals, while Inconel probes are preferred for a high-temperature range.
There are different types of thermocouple probes based on the type of tip in use. These include exposed grounded, and ungrounded thermocouples.
A grounded thermocouple has the tip of the thermocouple wires touching the wall of the housing tube. Grounded thermocouples are well known for their fast reaction to different temperatures. However, the tip is more exposed to electrical ground loops.
On the other hand, in an ungrounded thermocouple, a layer of insulation is used to separate the device’s tip from the walls of the housing tube.
With exposed thermocouples, the tip of the sensor extends to the exterior of the housing tube, providing a better measurement of air temperatures. Thermocouples with an extension wire provide better response time.
How Does a Thermocouple Work?
A thermocouple is made up of two wire legs, including the negative leg and positive leg, each designed with a set of unique material compositions.
The tip of the thermocouple wires connected to a thermocouple sensor is known as a hot junction. Its primary role is to measure an unknown temperature. The other end of the wires, well known as the cold junction, is the termination edge of the device, providing a known temperature. The temperature difference across these two junctions provides the actual temperature measurements.
Essentially, a thermocouple probe takes into account the unknown temperature and compares it with the known temperature to give a correlated temperature of what the device is measuring.
Pairing Thermocouple Wires
For thermocouples to be highly effective and efficient, the dissimilar wires must have a wide variance in electronegativities. This is to allow voltage readers to record the largest difference in thermoelectric voltage.
The best wire pairings are generated by base metal thermocouples. These are thermocouple sensors known for producing extremely high thermoelectric voltages. They include type E, K, T, J, and N thermocouple types.
On the other hand, noble metal thermocouples produce lower thermoelectric voltages. However, they can record extremely high-temperature changes. Noble metal thermocouples include Types B, S, and R.
The Seebeck Effect of a Thermocouple Probe
The functionality of a thermocouple is founded on a thermoelectric principle known as the Seebeck effect.
The principle suggests that electromotive energy is produced when the junctions of two conductors are connected, which varies with different metals.
The primary design of a thermocouple applies two dissimilar wires joined from both edges to form the measuring and connection points. Temperature changes are detected at the measuring point, while the connection point records the produced voltage.
Cold Junction Compensation
Since thermocouples only record the differential temperatures between the connection and measuring points, a cold junction is required to provide more accurate measurements.
The two points of the thermocouple are maintained at the same temperature while the two edges are correlated. The degree of temperatures measured is relative to the size of the thermocouple wire. Thicker wires produce higher temperatures at a lower response time and vice versa.
